9 kg ABC Fire Extinguisher (MAP 90 Based Cartridge Operated)

Code : KFDRQ-9-90%

Key Features:

Good quality MAP powder capable of fighting class A,B,C & Electrical fires
Co2 gas cylinder confirms to IS: 4947.
Brass chrome plated valve
Internally Epoxy polyester and externally pure polyester powder coating
Best available Fire ratings in its class.
Latest BIS approved – (IS 15683:2006) and ISI marked.
More flexible EPDM hose with less prone to cracks.
Tamper seal to detect any mishandling.
Anti-corrosive Phosphate treatment of Cylinders.
Large loop stainless Pull pin.
Lever lock for better handling.
Bar Code labeling for better traceability.
Easy to maintain, recharge & service.

Techniclal Specifications:

MODEL	KFDRQ-9-90%
Capacity	9 kg
Fire Rating	6A:233B
Diameter (Approx.)	180±10 mm
Average Range of throw	5 m
Operating Temperature	-30 °C to +60 °C
Expelling Agent	Co2 gas
Full Weight (Approx.)	15.3 kg
Shipping Weight (Approx.)	15.8 kg
Mounting Bracket	Wall bracket
Design	Hose & Nozzle
Height (Approx.)	585 mm
Average Discharge Time	30 Sec.
Average Discharge	95%
Service/Max. service/Test Pressure	15 / 17 / 35 bar
Co2 gas cartridge	200 gm
Empty Weight (Approx.)	6.3 kg
Packing Standard	2 in 1 - 24.5"X15.3.0"X8.0"
Approvals	BIS
