Honeywell North® PA700 Series Powered Air Purifying Respirator (PAPR)

Technical Specifications:

COMPONENT AND ATTRIBUTE SPECIFICATION Operating Conditions Temperature +10°F (-12°C) to +118°F (+48°C) (Note: A low-battery alarm will be triggered if the internal temperature of the battery reaches 48C) Humidity 20 – 90% R.H. (non-condensing) Altitude 0 – 10,000 ft above sea level Ingress Protection IP65 with battery, breathing tube, filter cartridge and cartridge cover installed Storage Conditions Temperature Daily: -4°F (-20°C) to +95°F (+35°C) Ideal: 40°F (5°C) to 68°F (20°C) Blower Housing Material PC/ABS Weight 1.77lbs (805g) Air-Flow (loose-fit configurations) 7.2CFM (205lpm) ; Nominal – Default 7.8CFM (220lpm) Nominal – Medium 8.3CFM (235lpm) ; Nominal – High Air-Flow (tightfit configurations) 5.5CFM (155lpm) Nominal Alarms Audible, Visual and Vibratory (See user-instructions for details regarding alarm triggers and sequencing) Motor Life >10,000 hours (est.) Noise Level <75 dBA (average measured at the ear) Battery Pack Materials Housing: PC/ABS Latch: Nylon Gasket: Open-cell silicone foam Weight 0.9lbs (410g) Chemistry Lithium-Ion Capacity 10.9V, 6700mAh, 73wH Run-time ?8hr (average)* Safety Short circuit/Overload/Over voltage/Over temperature protection Service Life Minimum 500 charge/discharge cycles while maintaining at least 70-80% of the original capacity* Shipping UN38.3 certified for air-transportation (Always consult a logistics professional for information regarding proper shipment of li-ion battery packs) Includes: PA111EU Hood
